Changzhou Dali Plastics Machinery Co., Ltd. always devotes unlimited efforts to the research and development of products. By virtue of continuous technological innovation, we have mastered the core and most advanced technology in the industry, and will use advanced technology to produce Hot New Products hdpe geomembrane waterproof sheet production line with high performance, effectively solving the pain points that have always plagued the industry. Since the beginning,Changzhou Dali Plastics Machinery Co., Ltd. have been sticking to the business principle of 'integrity' and bearing the mind of 'offering customers the best of us'. We are fully confident that we will make a great success in the future.
| Application: | Sheet, Film, sheet | Plastic Processed: | PE, HDPE/PP, Lldpe, LDPE, HDPE, LDPE,EVA, TPO |
| Condition: | New | Screw Design: | Single-screw |
| Screw Material: | 38CrMoALA | Screw diameter (mm): | 160 |
| Screw L/D Ratio: | 33:1 | Screw Speed (rpm): | 60 rpm |
| Showroom Location: | Turkey, Viet Nam, Philippines, Indonesia, Russia, Ukraine | Place of Origin: | Jiangsu, China |
| Brand Name: | Dali 8000mm wide PE Geomembrane machine | Voltage: | 380V 50HZ |
| Dimension(L*W*H): | 20mx16mx4.5m | Power (kW): | 980 |
| Weight: | 138000 KG | Warranty: | 1 Year |
| Key Selling Points: | Competitive Price | Applicable Industries: | Building Material Shops, Manufacturing Plant, Other |
| Marketing Type: | Hot Product 2022 | Video outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Warranty of core components: | 1 Year |
| Core Components: | Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox, Screw | After-sales Service Provided: | Engineers available to service machinery overseas |
| Mould: | flat head | Calender: | three roller |
| Cooling method: | water | Winder: | Friction winder |
| Certification: | CE | Automatic Grade: | Automatic |
Adopting calendering compound process to heat, extrude, press, cool LDPE, LLDPE, EVA and other raw materialS. It is used for producing monolayer and multilayer geocomposite from various kind of geotexitlenon-woven fabrics and woven fabrics.
It can be designed into computer automatic control, with vector frequency converter, PLC integrated control, human friendly interface and touch screen displayer.
|
Main technical parameters of HDPE liner geomembrane for landfill: |
| Suitable fabrics |
Geotextile,Plastic woven fabrics,Non woven fabrics
|
|||
| Model and specifications |
3300
|
4500
|
6300 | 8300 |
| Laminate layers |
one farbric one film,two fabrics one film,flashing
|
|||
|
Thickness of compound film (mm)
|
0.2-2.5
|
|||
|
Flashing thickness(mm)
|
0.5-2.5
|
|||
| Main machine power(kw) |
75 - 150
|
|||
| Specifications of embossing roller (mm) |
400×3300
|
500×4500
|
600×6300
|
800×8300 |
| Max. compound width |
3000
|
4200
|
6000 |
8000 |
| Cooling method |
Circulating water cooling
|
|||
| Remarks: The machine can be designed and manufactured according to the customer's requirement |
Sanitation Project(MSW landfill,sewage treatment,toxic and hazardous compounds disposal sites storage of dangerous goods);
Water Conservancy(rivers,lakes water reservoir dam seepage control and stopping leaks and consolidation and the impermemeable drains);
Construction Projects(subwayconstruction,building underground engineering and the roof garden impermeable,sewage pipe linging);
Landscape Works(artificial lake,pool);
Agricutural Engineering(reservoir,drinking water tanks,water storage pound the irrigation system impervious);
Transportation(highway) and so on.
Take advantage of our unrivaled knowledge and experience, we offer you the best customization service.
The first thing we do is meeting with our clients and talk through their goals on a future project.
They are all manufactured according to the strictest international standards. Our products have received favor from both domestic and foreign markets.
They are now widely exporting to 200 countries.
