Geomembrane sheet extrusion line
VR

Changzhou Dali Plastics Machinery Co., Ltd. boasts strong R&D capabilities and has been working on product development for years. Geomembranas Maquina HDPE is our newly-developed product and goes on sale starting now. We offer buyer Geomembranas Maquina HDPE that they need at prices that fit their pocket. Changzhou Dali Plastics Machinery Co., Ltd. have the aspiration to become a leading enterprise in the market. To achieve this goal, we will continually follow the market rules strictly and make bold changes and innovations to cater to market trends.

Application:Sheet, Film, sheetPlastic Processed:PE, Lldpe, LDPE, HDPE, LDPE,EVA,
Condition:NewScrew Design:Single-screw, Double screws
Screw Material:38CrMoALAScrew diameter (mm):160
Screw L/D Ratio:33:1Screw Speed (rpm):55 rpm
Showroom Location:Egypt, Turkey, United Kingdom, United States, Brazil, Saudi Arabia, Indonesia, Pakistan, India, Thailand, Bangladesh, South Africa, Ukraine, NigeriaPlace of Origin:Jiangsu, China
Brand Name:Dali GeomembraneVoltage:customizable
Dimension(L*W*H):12mX4.5mX3.5mPower (kW):220
Weight:12 KGWarranty:1 Year
Key Selling Points:High ProductivityApplicable Industries:Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Energy & Mining
Marketing Type:New Product 2020Video outgoing-inspection:Provided
Machinery Test Report:ProvidedWarranty of core components:1 Year
Core Components:Bearing, Motor, PLC, Pressure vessel, Gearbox, ScrewMould:flat head
Cooling method:waterWinder:Friction winder
After Warranty Service:Field maintenance and repair serviceCertification:CE

  Geomembranas Máquina HDPE



• Feeding systems with pneumatic or helix loaders

• Extruder with screen changer

• Co-extrusion feedblocks for adjustment of layer ratio and layer distribution

• Flat Extrusion Die-heads

• Chill rolls where extruded melt is transformed into a film and quickly cooled down

• In-line triming equipment

• Sheet guiding system

• Surface winding unit

• Edge trim recycling system



Geomembranas Maquina HDPE can also be desinged to make lamination on top of many kinds of geotextiles, non-woven fabrics, woven fabrics.



Raw Materials & Finished Product Applications

Polymers of LDPE, LLDPE, HDPE, EVA can be efficiently extruded on DL series of geomembrane extrusion line.



Geomembranas Maquina HDPE Geomembranas Maquina HDPE    Geomembranas Maquina HDPE



Geomembrane applications:

• Sanitary project(Landfill,sewage treament,toxic and hazardous compounds disposal)

• Water conservancy(river,lakes water reservior dam seepage control)

• Construction projects(subway construction, roof garden, sewage pipe liner)

• Landscape Works(artificial lake, pool)

• Agriculture engineering(reservior, drinking water tanks, water storage pond, irrigation system)

• Transportation(railway,highway)



Main technical parameters of Geomembranas Maquina HDPE :

Model and specifications
3300
5300
6300
7300 8300
Suitable fabrics
Geotextile, Non-woven fabrics, Plastic woven fabrics
Laminate layers
Three layers, Two layers
Thickness of compound film (mm)
0.2-2.5
Main machine power(kw)
75-200
Max. compound width
3000
5000
6000

7000

8000

Heating power (kW)
90
280
300

400

500

Cooling method
Circulating water cooling
The machine can be designed and manufactured according to the customer's requirement.
