Thanks to the efforts of our staff,Changzhou Dali Plastics Machinery Co., Ltd. can launch our 2022 hot sell CE approved PE PP Sheet Complete Production Line with low price release meeting as scheduled. Our Plastic Extruders is supplied with a competitive price . The quality of the 2022 hot sell CE approved PE PP Sheet Complete Production Line with low price is at the leading level in the industry and is inseparable from the hard work and innovation of outstanding technical personnel. Compared with the traditional ones, it better meets the market demands.
Application: | Sheet, Film, Extrusion lamination | Plastic Processed: | PE, HDPE, HDPE/PP, Lldpe, LDPE, Other, LDPE/LLDPE/HDPE/EVA |
Condition: | New | Screw Design: | Single-screw |
Screw Material: | 38CrMoALA | Screw diameter (mm): | 160 |
Screw L/D Ratio: | 33:1 | Screw Speed (rpm): | 60 rpm |
Showroom Location: | Turkey, India, Russia, Ukraine | Place of Origin: | Jiangsu, China |
Brand Name: | Dali | Voltage: | 380V 50HZ |
Dimension(L*W*H): | 20mx10mx3m | Weight: | 136000 KG |
Warranty: | 1 Year | Key Selling Points: | Competitive Price |
Applicable Industries: | Building Material Shops, Manufacturing Plant, Other | Marketing Type: | Hot Product 2022 |
Video outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Warranty of core components: | 1 Year | Core Components: | Bearing, Motor, Pump, Gear, PLC, Other, Pressure vessel, Engine, Gearbox, Screw |
After-sales Service Provided: | Engineers available to service machinery overseas | Machine width: | 4300mm |
Lamination width: | 4000mm | Lamination thickness: | 0.2mm -2.5mm |
Chill roller: | circulating water | Automatic Grade: | Automatic |
Certification: | CE |
Adopting calendering compound process to heat, extrude, press, cool LDPE, LLDPE, EVA and other raw materialS. It is used for producing monolayer and multilayer geocomposite from various kind of geotexitlenon-woven fabrics and woven fabrics.
It can be designed into computer automatic control, with vector frequency converter, PLC integrated control, human friendly interface and touch screen displayer.
Main technical parameters of HDPE liner geomembrane for landfill: |
Suitable fabrics |
Geotextile,Plastic woven fabrics,Non woven fabrics
|
|||
Model and specifications |
3300
|
4500
|
6300 | 8300 |
Laminate layers |
one farbric one film,two fabrics one film,flashing
|
|||
Thickness of compound film (mm)
|
0.2-2.5
|
|||
Flashing thickness(mm)
|
0.5-2.5
|
|||
Main machine power(kw) |
75 - 150
|
|||
Specifications of embossing roller (mm) |
400×3300
|
500×4500
|
600×6300
|
800×8300 |
Max. compound width |
3000
|
4200
|
6000 |
8000 |
Cooling method |
Circulating water cooling
|
Remarks: The machine can be designed and manufactured according to the customer's requirement |
Sanitation Project(MSW landfill,sewage treatment,toxic and hazardous compounds disposal sites storage of dangerous goods);
Water Conservancy(rivers,lakes water reservoir dam seepage control and stopping leaks and consolidation and the impermemeable drains);
Construction Projects(subwayconstruction,building underground engineering and the roof garden impermeable,sewage pipe linging);
Landscape Works(artificial lake,pool);
Agricutural Engineering(reservoir,drinking water tanks,water storage pound the irrigation system impervious);
Transportation(highway) and so on.
Extruder
Calender Part
Pulling Part
Winder
Take advantage of our unrivaled knowledge and experience, we offer you the best customization service.
The first thing we do is meeting with our clients and talk through their goals on a future project.
They are all manufactured according to the strictest international standards. Our products have received favor from both domestic and foreign markets.
They are now widely exporting to 200 countries.
