Dali has a collection of Isolation suit film making machine Nonwoven Fabric Lamination film Coating Film making Machine available from manufacturers around the world so if you'd like to buy some, do give a look. Now you can easily find the best suppliers to get the top of the line quality of Isolation suit film making machine Nonwoven Fabric Lamination film Coating Film making Machine and get lower prices. Changzhou Dali Plastics Machinery Co., Ltd. aims to become the most influential enterprise in the world. In order to achieve this goal, we will insist on introducing high-tech talents and learning international advanced technology, and strive to improve technical strength and gain the initiative in competition.

Application:FilmPlastic Processed:PE, EVA, Lldpe, LDPE
Condition:NewScrew Design:Single-screw
Screw Material:38CrMoALAScrew diameter (mm):120
Screw L/D Ratio:33:1Screw Speed (rpm):1480 rpm
Showroom Location:Egypt, Turkey, Viet Nam, Indonesia, India, Russia, MalaysiaPlace of Origin:Jiangsu, China
Brand Name:DaliVoltage:380V
Dimension(L*W*H):14000x12000x4000Power (kW):280
Weight:38000 KGWarranty:1 Year
Key Selling Points:Competitive PriceApplicable Industries:Garment Shops, Manufacturing Plant, Home Use, Other
Marketing Type:Hot Product 2022Video outgoing-inspection:Provided
Machinery Test Report:ProvidedWarranty of core components:1 Year
Core Components:Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox, Screw, T-dieAfter-sales Service Provided:Engineers available to service machinery overseas
Suitable fabrics:plastic woven fabrics, nonwoven fabrics, paperThickness of compound film:0.015-0.2mm
Heating power:160kwCooling method:circulating water cooling
Lamination:nonwoven laminationFinal product:Isolation suit film
Winder:automatic lamination machineBrand:Dali nonwoven lamination machine
Certification:CE

Product Overview

Isolation suit film &Nonwoven fabric laminating film making machine

Nonwoven lamination machine is a complete product line adopting casting extrusion process.
PE or PP material mixed with addtives is fed through feeding system to extruder and flat head extrusion die. Hot melt is coated on top of base fabric or paper from the unwinder passing calender rollers for forming and chill down, Then guided by pulling rollers and trimmed by two knives on both sides, the coated material is take up into rolls at winder station.
PRODUCT SPECIFICATIONS
No
Model&Specification
DL-1800
DL-2000
DL-2400
DL-2600
1
Working width
1600mm
1800mm
2200mm
2400mm
2
Thickness range of Laminating film
0.01-0.1mm


3
Laminate layers
Three layers,two layers,Multi-layers


4
Suitable fabrics
Woven fabrics,Non-woven fabrics,EVA Foam,Paper etc.


5
Screw diameter L/D
φ90 33:1
φ100 33:1
φ110 33:1
φ1200 33:1
6
Installation power
110KW
130KW
160KW
180KW
7
Machine size
14000X12000X4000mm


Note: All the machines can be manufactures according to customer's requirement.
Max. torque
500N.m


Usage

Be suitable for laminating floor mat, nonwoven-fabrics cloth, paper, woven cloth,
geotextile with mono-layer or multi-layer or multi-layer film. All can be designed and made according to customers’ requirements.
Final products sample
